Posts

How to Use LAUNCH LX CAN Diagnostic Cables on Li Auto L-Series?

Since 2022, Li Auto L-Series models have been equipped with an additional security gateway module that requires the LAUNCH LX CAN Diagnostic Cables for diagnostic access. This guide uses a 2023 Li Auto L8 and the LAUNCH X431 PAD7 to demonstrate the cable connection procedure. Required Tools LX CAN Diagnostic Cables X431 PAD7 / PAD5 / PRO3S+ V5 The blue plug connects to the security gateway, the other end to the vehicle network, and the dual plugs to the diagnostic port. Disconnect the High-Voltage & Low-Voltage Systems On the infotainment screen, go to Vehicle >> Maintenance >> Vehicle Power >> Turn Off The Power >> Close. Open the front hood and remove the upper cover. Locate the connector, release the white locking clip underneath by hand, and gently unplug it to disconnect the high-voltage system. Open the trunk, remove the upper guard plate and accessory box. Loosen and disconnect the negative battery terminal to power off the low-vol...

How to Use AI Workspace Feature in LAUNCH X431 Tool

 The LAUNCH X431 diagnostic tool has introduced an "AI Workspace" feature; when you encounter vehicle faults or need to determine which functions to execute, you can follow the recommendations provided by this "AI Workspace." Using the LAUNCH X431 PRO3 as an example, this article explains how to access the "AI Workspace" function on a 2020 JAC Shuailing E truck. Operating Procedure: 1) Select [Diagnose] -> [JAC] . It is recommended to use the JAC truck diagnostic software, version V12.11 or higher. Press enter or click to view image in full size 2) Select the vehicle model, then click [Automatic Scan] -> [High-speed Scan] . Press enter or click to view image in full size 3) You will notice that the new version of the software includes an [AI Workspace] option; click on [AI Workspace]. Press enter or click to view image in full size The AI Workspace can analyze issues based on the displayed fault codes and provide correspo...

Introduction to LAUNCH X431 Diagnostic Software Updates

 This article provides an overview of the LAUNCH X431 diagnostic software, covering topics such as the meaning of the icons within the software and whether it can still be used after the subscription expires. We will use the LAUNCH X431 PRO3 device as an example. To begin, open the X-431 app and select [Diagnose] from the main menu. Grey icons indicate software not yet downloaded, Click to start download. Installation packages vary in size; smaller files download faster while larger ones take longer. NOTE: Downloading in the [Software Update] is recommended for convenience. Press enter or click to view image in full size Tip: Long-press a software icon to add it to favorites for quick access. A green ring at the bottom-right of the icon means a new version is available, click the ring to update; If you do not want to update the software, click the main area of the icon to launch the software. A prohibition icon at the bottom-right signals an expired license....

How to Replace 2022 VW Viloran TPMS Sensor with LAUNCH CRT5011

 A 2022 VW Viloran came in with a TPMS warning on the instrument panel. I used the LAUNCH Creader TPMS 5011 V2 (CRT5011) to check the sensors and replace the faulty one. Here’s how it went. Identify the Failed TPMS Sensor Connect the CRT5011 and follow the vehicle selection path: TPMS >> VOLKSWAGEN >> Viloran >> 2022/01–2025/12 (433MHz) [30D907251] >> Active Activate the wheel sensors one by one. The FR, RR, and RL sensors respond successfully, but the FL sensor fails to activate. This confirms that the FL wheel sensor is faulty. Program the Replacement LTR-05 Sensor Select Programming >> Auto and wait for the CRT5011 to complete programming. Check the programming result on the screen. You can also use either of these methods: Manual: Enter the original vehicle sensor ID. Copy by OBD: Copy the sensor ID through the OBD connection. Note: If the instrument panel does not display tire pressure readings after programming with Manua...

LAUNCH X431 PRO3: TCM Fast Learn Resolves Shift Anomalies in MG6 Car

 The LAUNCH X431 tool can resolve shifting anomalies caused by loss of adaptive data after vehicle transmission repair by executing the "TCM Fast Learn" function. This article explains how to execute this function on a 2018 MG (SAIC) New MG6 using the LAUNCH X431 PRO3 V+ ELITE . Function Description: This function is a static adaptive calibration procedure for the TCM (Transmission Control Module). Under the command of the diagnostic tool, and with the vehicle stationary, the TCM automatically completes the calibration and writing of the clutch fill time, oil pressure compensation, and shift adaptation parameters, rebuilding the transmission adaptive learneda values in a single operation. It resolves shift abnormalities caused by the loss of adaptive data after transmission repair. Tested Model: 2018 — MG (SAIC) — New MG6 Supported equipment: X431 PRO series , X431 PRO3 series , X431 PRO5 , and X431 PAD series , the current one for Demo is X431 PRO3 V+ ELITE...

Can LAUNCH CRP919 EV View Voltage Data For Various Modules?

  Question : Can the LAUNCH CRP919 EV scan and display voltage data for various modules and individual battery cells in electric vehicles? Answer : Yes, it supports these functions. Please note that while the CRP919 EV is compatible with most electric vehicles, some specific models — such as new energy trucks — may require specialized adapters for diagnostics. Question : Do you mean the adapters and accessories included in the LAUNCH X431 EV diagnostic kit ? Answer : Exactly. If you haven’t purchased the CRP919 EV yet, we recommend the LAUNCH X431 PRO3S+ EV , which comes with an accessory kit containing these adapters at no extra cost.

LAUNCH X431 Tool Split-Screen Function Introduction

 All-New Split-Screen Feature Now on LAUNCH X431 Scan Tool . Diagnose, verify, and reference repair data side-by-side on a single display without switching screens. The new Split-Screen feature on the X-431 Scan Tools provides true system-level multitasking. Technicians can instantly divide the workspace into two independent operating areas, allowing simultaneous execution of diagnostic operations alongside tech info search, third-party apps, or other functions within X-431 APP. The following walk through illustrates the workflow on the X431 PAD9. Operating logic across other compatible models is identical. 1) Locate and Tap the Split-Screen Icon Open the X-431 APP. Locate the Split-Screen icon on the bottom navigation bar and tap it to initialize split-screen mode. 2) Automatic Dual-Zone Division The display automatically splits into two independent operating zones. The left zone maintains the ongoing. X-431 APP interface, while the right opens the application laun...
